Discover more information about your Bosch appliance.
Model Number (E-Nr) DFS097A50B/03
Width
90 cm
Colour
Silver metallic
Installation typology
Built-in
Air circulation
Convertible
Total power of the motors
140 W
Type of control setting devices
LED, Low-lift pushbuttons
Number of speed settings
3-stages + intensive setting
Max. air extraction
408 m³/h
Boost position air extraction
758 m³/h
Sound power at max. speed (2010/30/EC)
54 dB
Sound power boost (2010/30/EC)
69 dB
Max. air recirculation
358 m³/h
Boost position output recirculating
496 m³/h
Sound power at max. speed (recirculation)
60 dB
Sound power boost (recirculation)
67 dB
Grease filter material
Washable aluminium
Energy efficiency rating
A
Total annual energy consumption
38.5 kWh/a
Height of the appliance
426-426/426-426 mm
Width of the appliance
898 mm
Depth
290 mm
Minimum distance above an electric hob
430 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
150 / 120 mm
No-return airflow flap
No
Length electrical supply cord
175.0 cm
Net weight
12.3 kg
Handle bar
enclosed
Appliance height exhaust air max
426 mm
Appliance height exhaust air min
426 mm
Appliance height recirculating max
426 mm
Appliance height recirculating min
426 mm
Minimum width for installation
524 mm
Maximum width for installation
524 mm
Depth for installation
290 mm
PrefectAir Sensor
No
Cooktop-based hood control
No
EcoSilence Drive - efficient and extra silent
EcoSilence Drive™
EcoSilence Drive™ operates almost friction-free, for quiet yet powerful performance.
Yes
Silence
Yes
Boost position
Yes
Delay Shut off modes
10 min
Remote control
No
Type of lamps used
LED
Number of lights
2
Total power of the lamps
6 W
Total luminance
615 lm
Colour temperature
Neutral (3.500 K)
Illumination type softlight
LED illumination
Energy-saving white LED lights provide clear and bright illumination for the hob area.
No
Color temperature control via smartphone with Home Connect
TemperatureLight
Go from warm to cool lighting in an instant with the LED light for your hood.
No
emotionLight Pro
No
Home Connect
No
Power consumption standby/display off
0.2 W
