Installing an Induction Hob

Induction cooktop, cookware, raspberries, kitchen utensils, wooden table, minimalist interior.

Here you will find tips on how to install your new appliance. Be aware that installation methods and measurements may vary from model to model. It's important to check the installation manual for model-specific details.

Installation options

1. Above a drawer

1. The worktop must have a mininum thickness of 30mm.
2. There must be a mininum distance of 65mm between the top of the working surface and the top of the drawer for ventilation.

Cooking pot on a stove with minimum and maximum dimensions indicated in millimeters.

2. Above an oven

1. The worktop must have a minimum thickness of 30mm.
2. The distance between the oven and the hob must be at least 5mm.
If the distance between the hob and oven must be increased, refer to the installation instructions for the oven.

Cooking pot, kitchen utensils, dimensions, minimalist illustration.
